Application scope:
Communication industry: Apple product data cable HDMI、RJ45、FPC、 High frequency head and other products are suitable for soldering this equipment;
Optoelectronic industry: LED displays, LED strips, LED rectifiers, LED ball lights, LED beads and other products are suitable for soldering this equipment;
Home appliance industry: Products such as air conditioning remote controllers, air conditioning control boards, computer speakers, and TV switch connectors are suitable for soldering this equipment;
Automotive industry: products such as ignition switches, fuel sensors, navigation systems, motorcycle flashlights, etc. are suitable for this industry soldering machineEquipment soldering;
Toy industry: Toy handle connectors, circuit boards, and other products are suitable for soldering this equipment.

Specification parameters:

Overall dimensions		915*800*1450（mm)
work schedule	X-axis	200mm
	Y-axis	250mm
	Z-axis	50mm
	R-axis	±270°
Axial speed		0-500mm/s
Motion accuracy	XYZ axis	±0.01mm
	R-axis	±0.02°
Minimum diameter of laser light speed		0.2nm
Maximum output power		30W
focus distance		50mm
cooling method		Air cooling
Diode lifespan		Greater than 20000H
Program storage		999 of them
Focus machine size		31*57.4（mm）
fiber length		2m
ambient temperature		0－40℃
relative humidity		20％－90％
atmospheric pressure		0.4Mpa
power supply		220V 50Hz
weight		About 120kg
